Optical Luminescence Quenching Dissolved Oxygen Probe
Dissolved Oxygen

Optical Luminescence Quenching Dissolved Oxygen Probe

Model Number
DX530 | DX 532 | DX535
Price

$

Standard Lead Time
3 weeks

DX 530 – Economic field sensor
Ideal for freshwater aquaculture, river monitoring, well analysis, and wastewater control. Paired with devices like the PRO D01, it offers a highly competitive and reliable measurement solution.

DX 532 – Robust sensor with depth measurement
Built for harsh environments such as wastewater and seawater aquaculture. Its integrated hydrostatic depth measurement and strong water protection enable easy recording of oxygen saturation profiles and identification of thermoclines down to ~30 m.

DX 535 – Compact 12 mm lab-style sensor
Suited for near-surface waters and wastewater up to 1 m depth, and ideal for laboratory use. Its 12 mm design and non-consuming optical principle ensure maximum precision, e.g., for BOD measurements.

Request A Quote
Ask A Question

Key Specifications

Oxygen Saturation
DX530: 0.0 to 200.0 % | DX532 & DX535: 0.0 to 500.0%
Oxygen Concentration
DX530: 0.00 to 20.00 mg/l (ppm) % | DX532 & DX535: 0.0 to 50.0 mg/l (ppm)
Pressure
DX530: N/A | DX532 400 to 5,000 hPa | DX535: 500 to 1150 hPa
Depth Measuring Resolution
DX531 Only: 0.01m
Salinity
DX530: 0 to 50ppt | DX532 & DX535: 0 to 55ppt (ppt = parts per thousand)
Temperature
Fully automatic
Accuracy
DX530: 0 … 100 %: < ±0.3 mg/l 100 … 200 %: < ±3 % | DX532 & DX535: 0 … 100 %: < ±1 % 100 … 200 %: < ±2 %
Max Immersion Depth
DX530: 10m (3h per day) | DX532: 40m | DX535: 1m
Membrane Protection
DX530 & DX532: Included | DX532 Optional
Operating Temperature
DX530: 0 to 45°C | DX532: -5 … 50 °C | DX535: 0 … 50 °C

Available Accessories

Available Accessories

No accessories are set for this product.
No accessories are currently available for this item.
Request A Quote
Ask A Question
service icon
Calibration and service is available for this item.
Click here to request an RMA
