4 Channel Vibration Analyzer
Vibration Analysis / Accelerometers

4 Channel Vibration Analyzer

Model Number


Standard Lead Time

The HD2030 is a portable vibration analyzer able to perform spectral and statistical analysis. The instrument can supply all the measurement parameters required by the current standards concerning operator protection from the risks associated with excessive vibration and is able to measure in hand-arm and whole-body modes. It is also possible to evaluate and quantify the annoyance experienced due to vibration in buildings.

The HD2030 satisfies the following standards:

  • ISO 8041:2005, ISO 5349-1:2001 (handarm vibrations)
  • ISO 2631-1, 2 and 4 1997 (whole-body vibrations)
  • IEC 61260: Octave and third octave filters satisfy class 1 specifications.
Request A Quote
Ask A Question

Key Specifications

Measurement Modes
Hand transmitted, Whole body, Building vibrations
Measurement Parameters
RMS, VDV, MTW, Peak, Max, Min
Frequency Weighting
Fz, Fc, Wh for hand-transmitted vibrations | Fz, Fa, Wb, Wc, Wd, We, Wj, Wk for whole body vibrations | Fz, Fm, Wm for building vibrations
Octave or third octave band spectral analysis
The range of spectral frequencies depends on the chosen application, see data sheet.
Statistical Analysis
The selected measurement parameter is analyzed in 1dB classes. Both the probability and the percentile graphs can be shown
Measurement Range
0.1m/s² to 7000 m/s² with HDP356A02 (Hand vibration measurement) | 0.0007m/s² to 7m/s² with HDP356B18 (building vibration measurement)
Inherent Noise Level
Less than 30mm/s² with accelerometer HDP356A02 for hand-arm measurements and Wh filter
Linearity Range
Three ranges of 80dB overlapped by 70dB
PC Communication
RS322 and USB type
Power Supply
(4) Alkaline AA batteries, 10 hour life
