Level Switch
Stainless Steel Simple Bilge Level Switch
Simple electromechanical level switch made from AISI-316L stainless and armored cable.
- Bilge Pump operating sensor
- Easy to test after installation
- Fixed switch point
- Available with combined certification RINA + ATEX
- NAVAL certified cable output as standard – 5 mt and 10 mt standard
Request A Quote
Ask A Question
Key Specifications
Float and guide rod and body material
AISI-316L
Switching point
Fixed
Max working pressure
10 bar
Electrical contact
SPDT 203V 1A AC/DC
Armored cable
5 & 10 meters, others available upon request
Ambient temperature range
-30 to +55C - 90% RH
Max working temperature
105C
Fluid density to lift float
>0.65g/cm^3
Minimum degree of protection
IP 68
Available certifications
RINA Naval and Exia ATEX Certification
Available Accessories
